Hisaki Japan Manual Pallet HPT50-685 Capacity 5 TONNES WIDE
KSh115,000.00
Key Highlights & Commercial Advantages
-
Extreme 5-Ton Load Capacity: Specifically constructed to move dense, ultra-heavy loads that exceed the limits of standard 2.5-ton or 3-ton pallet jacks, such as industrial generators, transformers, stone blocks, and heavy machinery.
-
Standard Wide Fork Layout (685mm): The 685 mm overall width provides maximum balance and stability under heavy loads, fitting wide Euro pallets, industrial wooden crates, and machinery bases without tipping.
-
Reinforced Hydraulic Pump Assembly: Features an upgraded heavy-duty hydraulic cylinder casting designed to withstand immense hydraulic pressure without fluid leakage or cylinder wall deformation.
-
Heavy-Gauge Steel Reinforcement: Built with extra-thick steel forks, reinforced gussets, and solid linkage bars underneath each fork to prevent frame bending or twist under 5,000 kg loads.
Key Specifications & Technical Details
| Specification | Details |
| Model | HPT50-685 |
| Brand | Hisaki Japan |
| Load Capacity | 5.0 Tonnes (5000 kg / 11,000 lbs) |
| Fork Configuration | Wide Model (685 mm overall width) |
| Fork Width x Length | 685 mm (Outer Width) x 1220 mm (Fork Length) |
| Min. / Max. Fork Height | ~85 mm (Lowered) to ~200 mm (Max Lift) |
| Pump Type | Reinforced cast-steel hydraulic cylinder with high-pressure safety bypass valve |
| Wheels & Rollers | Steel-core Polyurethane (PU) / Cast Iron tandem load rollers and heavy steering wheels |
| Control Handle | Reinforced 3-position ergonomic lever (Raise, Neutral, Lower) |
| Chassis | Extra-thick reinforced structural steel frame with heavy-gauge under-fork push rods |
